Wall Printer Floor Printer Board DX5 Single Head Print Kit Inkjet Printer System
| Place of Origin | Changsha, China |
|---|---|
| Brand Name | BetterPrinter |
| Model Number | U2EWMB_V104，WHB_DX5_1J_V103，DX5 |
| Minimum Order Quantity | 20 sets of |
| Packaging Details | Carton |
| Delivery Time | 3-10 work days |
| Payment Terms | Bank transfer / WeChat / Alipay |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| MAIN BOARD SPECIFICATIONS | 182mm*112mm | HEAD BOARD SPECIFICATIONS | 63mm*123mm |
|---|---|---|---|
| Applicable Model | 4720,W5113,I3200,TX800,XP600,DX5,DX7,7610 | Color | Blue,Green |
| Use For | Industrial Inkjet Printer | Nozzle Model | DX5 Printhead |
| Type | Kit Board | Feature | Original And Brand New |
| Highlight | DX5 Inkjet Print Circuit Board,DX5 Printhead Print Circuit Board,DX5 Printhead Control Board double head |
||
Product Description
Wall printer floor printer inkjet board low cost DX5 single head print kit inkjet printer system
Quick Details:
USB2.0 DX5 Single head inkjet printing control system, connected by flexible flat cable, cost-effective,stability .
| Name: DX5 Single Head Printer Inkjet Board. |
| Function support: Anti-collision and continuous printing, automatic height measurement, variable point printing, device power failure and continuous printing, automatic reset, disconnection and continuous printing, paper out detection, ink stack self-check, etc. |
| Data interface: USB2.0 cable to connect to the computer, flexible flat cable to the head board. |
| Color channel: 8 channels/8 colors. |
| Nozzle features: Can print water-based, thermal transfer, paint, eco-solvent, UV and other inks. |
| Nozzle protection: Nozzle reverse connection protection, stimulating nozzle (flash spray), short circuit protection. |
| Board support: Single head, double head, three head, four head, eight head, sixteen head, thirty-two head. |
| Trolley speed: 1.2M/S. |
| Effective print width of print head: 1 inches. |
| RIP-software: Mainstream RIP software such as MainTop, Photoprint, UltraPrint, ONYX, Wasatch, etc. |
| Application field: Advertising photo printing, UV coil, textile printing and other industries. |
Application machine:
Wall Printer, Floor Printer, photo Printer, small-format flatbed printing, etc.
UV printing is a high-tech, plate-free, full-color digital printing. It is not limited by materials. It can be used on metal, plastic, sliding doors, sliding doors, glass, plates, various signs, crystal, PVC, acrylic, stone, leather, etc. Color photo-level printing on the surface. There is no need to make a plate and complete the printing at one time, with beautiful and rich colors, abrasion resistance, UV protection, simple and convenient operation, fast printing image speed, and fully conform to industrial printing standards.
The wall printer is a machine and equipment that prints patterns on the wall. It uses mobile printing to spray the patterns on the wall. You can paint on walls, rice paper, brick walls, diatom mud, ceramic tiles, glass, etc. You only need to set the picture size to paint. Wall printers have low printing costs, high printing accuracy and better results, which can save time and labor.
Application scenario:
Phone case color printing Advertising printing Ground painting
Detailed Images:
Printer Inkjet Board DX5 suit
Single head board
Main board
Notice before shipment:
• If you have any requirements or questions about our products, please contact us. We will reply you within 12 hours.
• If you have any questions about the goods (type, which type) in the invoice and the declared value of the order, please leave us a message after payment to avoid sending the wrong order. If not, we will ship according to the default order.
• Please ensure that your address and contact information are correct and complete. If you want to exchange or need more products, please update before payment.
Seller promise:
1. We guarantee that the product kit will be completely delivered according to the product list.
2. We will provide printing software and wiring diagram after the buyer receives the goods.
* If you need more information, please contact us.
